Magewell Ultra Encode SDI Plus Module

Magewell Ultra Encode SDI Plus Module: Multi-Protocol SDI Encoding for Modator Chassis

The Ultra Encode SDI Plus Module takes SDI video input and encodes it to H.264 or H.265, then delivers the output over IP via SRT, NDI, RTMP, and other streaming protocols. It is the module version of Magewell's Ultra Encode SDI Plus, designed for the Modator Chassis 2U. Up to eight modules can be installed in a single chassis, giving you up to eight independent SDI encoding channels in 2U of rack space with shared power and management.

At £446 per module, it brings professional-grade, multi-protocol SDI encoding into the Modator ecosystem where scalable channel counts are needed in a compact footprint.

What This Module Does

The module accepts an SDI input signal, encodes the video using H.264 or H.265 compression, and streams the result over the network using one or more of the supported output protocols:

• SRT (Secure Reliable Transport): for contribution and distribution over the public internet where network conditions are variable and reliability is a requirement
• NDI: for delivery into NDI-based production environments, software decoders, and other Magewell devices on the local network
• RTMP: for direct delivery to streaming platforms including YouTube Live, Facebook Live, and other RTMP-capable CDNs
• RTSP and other standard protocols for local network streaming, recording, and monitoring applications

Each module in the chassis operates independently, with its own SDI input and its own output protocol configuration. You can have eight modules encoding eight completely different SDI sources to eight different destinations simultaneously.

Why Stack Multiple Encoding Channels

Multi-channel encoding in a single rack unit is useful wherever several SDI signals must be converted to IP simultaneously. A sports venue might need to encode feeds from multiple camera positions for remote production or streaming. A broadcast facility might need to send multiple programme feeds to remote contributors via SRT. An OB truck might need a compact, reliable encoding rack that can be transported and deployed quickly.

Eight Ultra Encode SDI Plus modules in a fully populated Modator chassis deliver eight independent encoding channels in 2U with a single shared power connection. The equivalent eight standalone Ultra Encode units would occupy far more rack space and require eight separate power supplies.

Who Needs This Module

• Broadcasters encoding multiple SDI feeds to NDI or SRT for remote production and REMI workflows
• Sports and events venues converting multi-camera SDI feeds to IP for distribution and live streaming
• Live streaming operations needing multi-channel SDI-to-RTMP encoding in a compact and portable rack
• Post-production and playout facilities converting SDI sources to NDI for integration with software-based production workflows
• OB and flyaway operators building efficient, multi-channel encoding systems where every unit of rack space and every watt of power counts

Buying from StreamKit

• Authorised UK Magewell reseller
• 3-year manufacturer warranty included
• Free delivery to UK addresses
• UK-based technical support

The Modator Chassis 2U is sold separately. This listing covers the module only.
